Best Price Digital Foil Used Uv Printer Flatbed With To Roll 2022
TXC UV flatbed Printer (9060) features
1. 3 heads: CMYKlclm+W+Varnish.2. Ideal for customizing pre-manufactured items, promotional goods, fine art and unique signs.3. Precision and quality print on a wide variety of substrates including acrylic, wood, board, metal, glass, plastic, PVC, up to 100mm high and 30kg in weight.4. Print colorful images on demand, to personalize or customize small or medium-sized items, from a single object up to a short-run production runs.5. Produce 3D embossed and varnish effects using varnish.6 The UV flatbed printer equipped with bi-directional printing function, it can increase printing speed and efficiency.7. An automatic media height system for detecting the thickness of the substrate.8. A special positioning jig is available to align items easily on the printing table.9. A Head refresh Feature removes any ink remaining on the printheads and cleans the printhead surface to maintain the health of the printer.10. Optional Rotary device available and optional vacuum table available.| UV Flatbed Printer Specification | ||
| Max printable size | 900*600mm | |
| Print head | 3 * EP XP600 heads/I3200 | |
| Motors | Servo motors | |
| Height adjustable | Automatic | |
| Media thickness | 1-100 (150mm, 200mm also optional) | |
| Print resolution | 2880*1440dpi | |
| Color | CMYKlclm+W+V | |
| Print speed | Average 7-10 square meters per hour | |
| Print Direction | Bi/Uni direction | |
| Ink type | UV environmentally ink | |
| UV lamp | 3* Led uv lamps | |
| Cooling type | water cooling | |
| UV power | 350W | |
| UV light wavelength | 390~400mm | |
| Ink type | UV environmentally ink | |
| Ink drop size | Min 3.5pl,max 28PI | |
| System requirement | Windows 7/8/10 | |
| Operational software | RIP software Maintop 6.1, Photoprint | |
| Printer size | 1900*1000*1050mm | |
| Net/Gross weight | 215KG/295KG | |
| Packing | Strong wooden package with fill foam | |
| Packing size | 2300*1200*1300mm | |
| Printer head maintain | Head clean during/after printing, keep-wet system when idle. | |
| Materials to print | Metal, plstic, glass, wood, ceramics, acrylic, leather,etc. | |
FAQ
1,What is UV printing?UV printing is a form of digital printing that uses ultra-violet lights to dry or cure ink as it is printed. As the printer distributes ink on the surface of a material, specially designed UV lights follow close behind, “curing” or “drying” the ink instantly.2, what material can I use for printing?In UV printing, the ink dot is left sitting on top of the media, since UV inks dry immediately when exposed to UV light. This gives way to printing on virtually almost anything, coated or uncoated, from plastics and glass to wood and metal.3, What color of material Can I use for printing?Our printers are designed to print on any colored material from white to black.4, How do I use the printer?The software needed to use the printer is included with any model. We also include a manual and training video to assist with learning how to use the printer. We are also available by phone or email to answer any questions you may have.5, Is warranty included?We include a two year warranty that covers all printer parts excluding the Epson printer head, cartridge and pump.6, Are replacement parts available?We offer all replacement parts for your printer with quick delivery to ensure your print has very little downtime. We offer 24/7 technical assistance for troubleshooting and repair.7, Is there any maintenance required:In order for any uv printer to be producing high quality results, maintenance is a must. We suggest powering the printer on once a day and performing a cleaning print to keep the head from drying. In the event that the printer has not been used for over 7 days, we recommend cleaning the printing head with cleaning liquid. Our printer manual provides detail information to properly maintain your printer and we provide all the necessary tools and cleaning supplies.
