Working Process
Using a transfer paper printer, you can easily print the patterns required by various customers, and achieve massproduction,pollution-free, simple operation, saving manpower, material and financial resources, which greatly reduces productioncosts.
Details Images
| Model | FD5194 Dye Sublimation Printer | ||
Printhead | Type | 4*EPi3200 ( 4 Epson 4720 ) | |
| Printhead | Nozzle Qty | 4pcs printheads | |
| Height to Platform | 2-5mm | ||
| Resolution | 3200 DPI | ||
Printing Speed | Production Mode | 2pass 180sqm/h | |
| Average Mode | 3pass 120sqm/h | ||
| High Resolution Mode | 4pass 90sqm/h | ||
Ink | Color | C M Y K | |
| Type | Dye Sublimation | ||
| Supply Method | Siphoning | ||
| Media | Transfer paper (20-100g) | ||
| RIP software | Maintop, Photoprint,Onyx,Wasatch and etc | ||
| Max Printing Width | 1900mm | ||
| Media Transfer Method | Auto air shaft feeding and take-up system | ||
| Drying Method | External,Intelligent and air-heat Integrated drying system | ||
| Moisture Mode | Fully sealed auto moisturing and cleaning | ||
| Image Format | JPG,TIF,PDF,BMP and etc. | ||
Computer | System | WIN7 64bit/WIN10 64bit | |
Hardware | Hard disk:500G (system disk more than 100G) GPU:ATI Discrete CD-ROM:DVD ROM Memory:4G or more CPU:Intel i5/i7 processor | ||
| Transmit Port | Gigabit LAN | ||
| Work Environment | Temperature 18-30 centi degree; Humidity 35-65% | ||
Power | Input Voltage | 210-230VAC 50/60HZ 16A | |
| Printing system | 1200W | ||
| Drying system | Max power 7200W | ||
Dimension | Printer Dimension | 3180*1100*1700mm | |
| Packing Dimension | 3380*1030*1790mm | ||
| Weight | Net Weight: 350KG Gross Weight:400KG | ||
Customer Photos
Certifications
Company Profile
Exhibition
FAQ 1.Q: What’s the machine installation?A: We provide the machine usage & installation videos and instruction manual, afford the 24 hour online service support for oversea customers. If need, we could provide the on-site installation and training service.
2.Q: How about the machine’s package and transportation ?
A:We will protect the machine with film and bubble film around the machine when it leaves the factory, and fix it on the bottom of the wooden case with iron nails. After the wooden case is packed, we will choose the mode of transportation according to the customer's requirements, and provide export service according to the customer's requirements.
3.How about the machine’s maintenance ?
A:With warranty of whole printer ( not included the printer head) , simultaneously we will provide the lifetime warranty if use together with our ink. Also our after-sales engineers will provide 24 hour online technical consulting service.
